Fostar Easy Installation Adjustable Height Automatically Car Hoist 2 Post Lift Vehicle
Overview Package size per unit product 56.00cm * 400.00cm * 78.00cm Gross weight per unit product 600.000kg Product Desc
Basic Info
Model NO. | QTY-240L |
Lifting Capacity | 4T |
Driving Type | Hydraulic |
Certification | CE, ISO, GS |
Driving Motor Number of Mechanical Lift | 1 |
Double Cylinder Lift Type | Planer-type |
Shearing Lift Type | Big Shear Type |
Condition | New |
Brand | Optical |
Design | Two Post |
Color | Blue/Red/OEM |
Column Height | 3660mm |
Max Lifting Height | 1750mm |
Driving Mode | Electric Hydraulic |
Lifting Time | Lifting Time |
Transport Package | Wooden Box |
Specification | 3T/4T/5T |
Trademark | FOSTAR |
Origin | China Zhuhai |
HS Code | 8425429000 |
Production Capacity | 5000pieces/Year |
Packaging & Delivery
Package size per unit product 56.00cm * 400.00cm * 78.00cm Gross weight per unit product 600.000kgProduct Description
Fostar ODM Safe Anti-deformation Double Column Gantry Hydraulic 2 Post Car Lift
* Automobile lift refers to the automobile maintenance equipment used for automobile lifting in automobile maintenance industry.Lifting machine plays a vital role in automobile maintenance, whether the vehicle overhaul, or minor repair and maintenance, can not be separated from it, its product nature, quality directly affect the personal safety of maintenance personnel. In the repair and maintenance enterprises of different sizes, whether it is the comprehensive repair shop of a variety of models, or the street shop of a single business scope (such as tire shop), almost all are equipped with a lift.* Ground lift without grooving, suitable for any repair shop, there are some floors are not suitable for the installation of two column lift and ordinary four column lift, and the machine and floor contact surface, so that can be installed in any can drive the floor above, to solve the problem of customer site. The biggest advantage of shear lifting machine is that it does not occupy space and is convenient to use. The disadvantage is that the oil balance requirement is very strict, and it needs to be equipped with control box, and the cost is more expensive.
Structure
1)The height of the column is 4.75mm thick steel plate, the column is not distorted, no deformation, high safety performance.2)Adopt high quality cylinder, cylinder quality guarantee for 3 years, free replacement of the cylinder during the warranty period.3)The transmission chain adopts a single 121 section 4×4 shield chain, quality assurance products.4)The power unit adopts the international famous brand of pure copper core motor.5)The safety lock will be automatically locked when rising to ensure the safety when rising.6)There are beam connections between the two columns, with a limiting device, to ensure safe power off.
Product Parameters
Height of column: | 3660mm |
Lifting weight (rated parameter) | 4000KG |
lift | MAX 1750mm |
Rise and fall time: rise | 45-60S |
Rise and fall time: fall | 15-25S |
Lifting arm rotation Angle | 90° |
Electric voltage: | 2.2KW/220V/380V |
Driving mode | Electro-hydraulic |
Machine weight | 570KG |
Product advantage1)Can be used for multi - station mobile automatic tracking system Four-wheel positioning survey2) Easy operation (With detailed instructions before delivery)3) Reliable quality, low failure rate4)Passed ISO quality system certification and export CE certification5)The appearance and color of the product are optional
Product quality:Universal packaging: Two packages1. The iron frame is packed with two main columns and bottom plate couplings, equipped with steel wire and other accessories.2. Carton packing an electric pump station assembly plus factory documents.3. Package size: 550*4000*750mm a piece,300*350*700mm one piece
